Main Range Compatibility PacDrive 3
Product Type Servo motor
Device Short Name SH3.....P
Complementary Specifications:
• Maximum mechanical speed: 6000 rpm
• Rated supply voltage [Us]: 115...480 V
• Network number of phases: Three phase
• Continuous stall current: 3.5 A
• Continuous stall torque: 2.94 N.m at 115...480 V
• Continuous power: 1190 W
• Peak stall torque: 9.6 N.m at 115...480 V
Nominal Output Power:
• 410 W at 115 V single phase
• 790 W at 230 V single phase
• 1410 W at 400 V three phase
• 1630 W at 480 V three phase
Nominal Torque & Speed:
• 2.91 N.m (1250 rpm) at 115 V
• 2.64 N.m (2500 rpm) at 230 V
• 2.27 N.m (5000 rpm) at 400 V
• 2.27 N.m (6000 rpm) at 480 V
Technical Details:
• Maximum current Irms: 12 A
• Shaft end: Parallel key (19 mm diameter, 40 mm length)
• IP degree of protection: IP54/IP65 (conforming to EN/IEC 60034-5)
• Encoder type: Absolute single turn SinCos Hiperface
• Holding brake: Without
• Motor flange size: 100 mm
• Rotor inertia: 1.4 kg.cm²
• Product weight: Standard
