Main Range Compatibility: PacDrive 3 | Device Short Name: SH3.....P
- Maximum mechanical speed: 6000 rpm
- Rated supply voltage: 115...480 V
- Continuous stall current: 3.5 A
- Continuous stall torque: 2.94 N.m
- Continuous power: 1190 W
- Peak stall torque: 9.6 N.m
- Nominal output power: 410W (115V) / 1630W (480V)
- Shaft diameter: 19 mm | Shaft length: 40 mm
- IP degree of protection: IP54 / IP65
- Encoder type: Absolute single turn SinCos Hiperface
- Motor poles: 4
- Stator resistance: 3.8 Ohm
- Stator inductance: 27.15 mH
- Maximum radial force: 900 N @ 1000 rpm
- Cooling type: Natural convection
- Product weight: Standard industrial grade
We provide a comprehensive range of automation components including: Modules, Frequency Converters, Motors, Drivers, HMI, Linear Parts, Gateways, Sensors, IGBT, IC, Circuit Breakers, Contactors, Encoders, and Timers.
Frequently Asked Questions
What is the warranty period for this servo drive?
We provide a 12-month warranty for all products sold, ensuring reliable performance and peace of mind.
What is the Minimum Order Quantity (MOQ)?
The MOQ for this model is 1 set, making it accessible for both small projects and large-scale replacements.
Which payment methods are accepted?
We accept various payment terms including T/T (Bank Transfer), Credit Card, Paypal, Alipay, and Wechat Pay.
How long is the delivery time?
Standard delivery typically takes 3 to 5 business days after order confirmation.
Is the product original and new?
Yes, we guarantee that the product is 100% New Original equipment.
What is the protection rating of the motor?
The motor conforms to EN/IEC 60034-5 standards, offering IP54 protection for the shaft bushing and IP65 for the motor body.
