Industrial Gear Lubricants for Enclosed Cylindrical Gears

i

Basic Information

Model NO.

2122PE

Composition

Base Oil

Property

Protective Lubricant

Shape

Liquid

Type

Gear Oil

Certification

ISO9001

Transport Package

Drum

Specification

200L

Origin

China

HS Code

3403990000

Production Capacity

100000 Pieces/Year

★

Product Description

Synthetic hydrocarbon heavy-duty industrial gear oil is refined using imported poly-α-olefin (PAO) as base oil, proprietary additive formulation technology and advanced production technology.

⚙

Main Performance

High viscosity index and good viscosity-temperature performance for wide temperature ranges.
Extremely low pour point for excellent low-temperature performance.
Extremely high oil film strength and excellent wear resistance for gear protection.
Superior oxidation and thermal stability for long service life.
Prevents colloid and carbon deposit formation.
Excellent wetting, adhesion to metals, and corrosion resistance.
Good anti-foaming and demulsification performance.

Meets Standards: U.S.S 224, AGMA 251.04, DIN 51517 Part III.

📊

Technical Indicators

ISO Viscosity Grade	100	150	220	320	460
Kinematic viscosity, 40ºC, mm2/s	100	150	220	320	460
Viscosity index	150	150	150	150	150
Flash point (open), ºC	245	245	250	250	250
Pour point, ºC	-45	-45	-43	-42	-35
Sintering load PD, Kg	400	400	400	400	400

* Typical performance data shown. Other viscosity grades can be customized.

✔

Application Areas

Suitable for lubrication of steel-steel paired closed cylindrical gears, helical gears, and herringbone gear transmissions with tooth surface contact stress greater than 1100N/mm2. It is ideal for heavy-load gear devices in:

Metallurgy Steel Cement Mining Petrochemicals

⇄

Equivalent Products Reference

Model	ESSO	BP	MOBIL	SHELL
2122PE	Spartan Synthetic EP	Enersyn EPX	Mobilgear SHC	OMALA S4 / WHEEL 460,680

?

Frequently Asked Questions

What is the base oil used in 2122PE gear oil?

The 2122PE series is refined using high-quality imported poly-α-olefin (PAO) synthetic hydrocarbon as the base oil.

Can this gear oil be used in extreme cold environments?

Yes, it features an extremely low pour point (down to -45ºC for certain grades), making it highly suitable for extremely low ambient temperatures.

Which industrial standards does this lubricant meet?

This product exceeds U.S.S 224, American Gear Manufacturers Association AGMA 251.04, and German standard DIN 51517 Part III.

What are the main applications for this gear oil?

It is designed for heavy-duty closed cylindrical, helical, and herringbone gears used in industries like metallurgy, mining, cement, and petrochemicals.

Are different viscosity grades available?

We provide standard ISO grades 100, 150, 220, 320, and 460. Other specific viscosity grades can also be customized.

How does it protect equipment under heavy loads?

It provides extremely high oil film strength and excellent wear resistance, with a sintering load PD of up to 400 Kg, ensuring protection for high-stress tooth surfaces.
